Hot Dipped Galvanized Steel Sheet Gi Sheet 4x8
Hot Dipped Galvanized Steel Sheet Gi Sheet 4x8
Class：Galvanized pipe Galvanized sheet
Time：2024-05-28
Introduction：WuXi Sylaith Special Steel Co., Ltd. is a large production and supply enterprise, is a collection of carbon steel sheet, seamless steel pipes, stainless steel sheet, stainless steel pipe, copper alloy, aluminum alloy, production, trade, export, logistics, service, new product development in one of the large steel enterprises.
PRODUCT DETAILS
Galvanized Steel Sheet DX51D+Z
Descriptions
What is hot dipped galvanized sheet?
Hot-dip galvanizing is a process of coating steel with a thin zinc layer, which serves as a barrier between the steel and the environment. The finish is applied by passing the steel through a molten bath of zinc at a high temperature.
SPECIFICATION PARAMETER | |
Product Name | Galvanized Steel Plate/Sheet |
Grade | DX51D+Z,DX52D+Z,DX53D+Z,DX54D+Z,DX56D+Z |
S250GD+Z,S280GD+Z,S350GD+Z,S550GD+Z | |
SGCC,SGCD,SGCE | |
Standard | ASTM,AISI ,JIS,DIN,GB,EN,etc. |
Zinc coated | 30-275g/m2 |
Spangle | Large Spangles,Regular Spangles,Small Spangles,Zero Spangles |
Surface treatment | Chromated,oiled/non-oiled and anti-finger printing |
Thickness | 0.3-3.0 mm or as required |
Width | 600-1250 mm or as required |
MOQ | 5TONS |
Substrate | Cold rolled ,Hot rolled |
Tolerance | Thickness:±0.01mm |
Width:±2mm | |
Packaging | Export standard package: bundled wooden box, suit for all kinds of transport, or be required. |
Application | construction,decoration,hardware,electric appliances,machinery and other industrial and |
Container | 20ft GP:5898MM(Length)*2352mm(Width)*2393mm(High) |
STEEL GRADE | CHEMICAL COMPOSITION % | MECHANIC PROPERTY | C.B OF COATING | ||||||
C | Si | Mn | S | p | T.S | Y.S | E.L | ||
x103 | x103 | x102 | x103 | x103 | Mpa | Mpa | % | d=180 | |
JIS G3302 SGCC | 12 | 30 | 41 | 31 | 21 | 480 | 300 | 13 | OK |
JIS G3302 SGCH | 12 | 10 | 21 | 18 | 6 | 680 | 650 | 20 | OK |
ASTM 653 CS.B | 29 | 30 | 60 | 35 | 30 | 386 | 250-380 | 20 | OK |
DX51D+Z | 20 | 21 | 18 | 1.8 | 11 | 355 | 245 | 38 | OK |
G550 | 12 | 6 | 73 | 5 | 17 | 715 | 654 | 8 | OK |
Details
Product Applications
Automobile: body plate, radio, fan, air filter, filter, fuel tank
Household appliances: refrigerator, washing machine, dryer, air conditioner, video recorder, CD player, color TV, tape recorder,microwave oven, stereo
Office machines: copiers, computer cases, printers, monitors, telex machines
Architecture: doors, walls, partitions, keels
Production machinery: agricultural machinery, industrial robot
Clean industry: operating room wall decoration
Others: distributor, oil storage tank, motor cover, steel furniture base plate
Packing
Package: 3 layers of packing,inside is kraft paper,water plastic film is in the middle and outside GI steel sheet to be covered by steel strips with lock,with inner coil sleeve
Loading Port:Tianjin/Qingdao/Shanghai Port.
